Description
|
item
|
value
|
|
Place of Origin
|
Shanghai, China
|
|
Brand Name
|
SK(shangkai) Yongxing
|
|
Model Number
|
KCD3-11-CB1B-B-G-01
|
|
Current Rating
|
6(3)A
|
|
Voltage Rating
|
250V AC
|
|
Mechanical Life
|
50000 Cycles
|
|
Contact Resistance
|
≤50mΩ
|
|
Insulation Resistance
|
≥1000MΩ
|
|
Dielectric Strength
|
1500VAC 1 Minute
|
|
Electronic Life (cycles)
|
10,000
|
|
Certificate
|
CQC CE ROHS
|
|
Circuit
|
SPST
|
|
Dimension Code
|
B1 ( 21.4x15x15.2 , 19.3×13.2×12.9)
|
|
Contact Piece Code
|
B (8 length, 4.8×0.8 standard)
|
|
Actuator Color
|
Red,Yellow,Green,Black,Blue,Orange,White,Gray
|
|
Switch Function
|
On Off
|
Why Choose Our Rocker Switch?
Our Rocker Switch stands out for its durability, with a mechanical life of 50,000 cycles and an electronic life of 10,000 cycles. It's certified with multiple international standards, ensuring safety and reliability. The switch is available in multiple colors, allowing for customization to match your design needs.
What Are the Key Specifications?
The switch has a current rating of 6(3)A and a voltage rating of 250V AC, making it suitable for a wide range of applications. Its compact size of 15x21mm and SPST circuit configuration provide versatility in use.
What Are the Advantages of Buying from Us?
As a direct factory supplier, we offer competitive wholesale prices and excellent after-sales service. Our switches are manufactured with high-quality materials and undergo strict quality control, ensuring consistent performance and reliability. Choose us for your Rocker Switch needs and experience the difference in quality and service.
