Description
Key Specifications:
- Max. Rating Current & Voltage: 3A 250V AC
- Contact Resistance: ≤50mΩ
- Insulation Resistance: ≥100MΩ
- Dielectric Strength: 1500V
- Electronic Life (cycles): Momentary: 50,000 | Alternate: 25,000
- Mechanical Life (cycles): Momentary: 200,000 | Alternate: 50,000
- Certification: CQC, CE
- Operating Temperature: -5℃~+75℃
- Protection Level: IP40
- Size: 12mm
Product Advantages:
Our switch stands out from the competition with its exceptional durability, high electrical ratings, and robust design. The self-locking mechanism ensures secure operation, while the momentary function provides quick and responsive control. With a long mechanical and electronic life, this switch offers excellent value for money and reduces the need for frequent replacements.
Applications:
This push button switch is suitable for use in a variety of applications, including industrial control systems, automotive electronics, home appliances, and more. Its compact size and reliable performance make it a versatile choice for any project.
After-Sales Service:
As a factory supplier, we are committed to providing excellent after-sales service. We offer a warranty on all our products and are always available to assist with any technical questions or concerns you may have.
Wholesale Availability:
We offer competitive wholesale pricing for bulk orders, making it easy for you to stock up on this essential component. Contact us today to discuss your needs and take advantage of our factory-direct pricing.
| Max. Rating Current & Voltage (Resistive Load) |
3A 250V AC |
| Contact Resistance | ≤50mΩ |
| Insulation Resistance | ≥100MΩ momentary push button switch |
| Dielectric Resistance | 1,500V 3 pin push button switch |
| Electronic life(cycles) | Momentary:50,000 Alternate:25,000 |
| Mechanical life(cycles) | Momentary:200,000 Alternate:50,000 |
| Certification |
CQC , CE |
| Operating temperature | -5℃~+75℃ |
| IP code | IP40 |
Why Choose Our Red 3A 250VAC Self-Locking Push Button Switch?
Our switch offers exceptional durability, high electrical ratings, and a self-locking mechanism for secure operation. With a long mechanical and electronic life, it provides excellent value for money and reduces the need for frequent replacements.
What Are the Key Features of This Switch?
Key features include a 3A 250V AC rating, ≤50mΩ contact resistance, ≥100MΩ insulation resistance, and a 1500V dielectric strength. It also boasts a long electronic life of 50,000 cycles (momentary) and a mechanical life of 200,000 cycles (momentary).
Is This Switch Suitable for My Application?
This switch is suitable for a wide range of applications, including industrial control systems, automotive electronics, and home appliances. Its compact size and reliable performance make it a versatile choice for any project requiring a high-quality push button switch.
