Description
**Specifications**:
– Place of Origin: Shanghai, China
– Brand Name: Sk(Shangkai), Yongxing
– Model Number: YX122-016-03P
– Type: Spring Terminal
– Rated Voltage: 300V
– Rated Current: 10A
– Contact Resistance: 20mΩ
– Insulation Resistance: >5000MΩ DC500V
– Withstand Voltage: AC2000V/Min
– Operating Temperature: -40℃~+150℃
– Contact Material: Brass, Tin Plated
– Poles: 2~16 poles
– Color: Green
– Certificate: CQC
**Advantages**:
– **Durable Construction**: Made with high-quality brass and tin-plated contacts for enhanced durability and corrosion resistance.
– **Wide Temperature Range**: Operates efficiently in extreme temperatures from -40℃ to +150℃.
– **High Insulation**: Ensures safety with insulation resistance exceeding 5000MΩ at DC500V.
– **Easy Installation**: Screwless design allows for quick and easy connections.
– **Versatile**: Suitable for a wide range of applications, from industrial machinery to home appliances.
**After-Sales Service**:
We stand behind the quality of our products. Should you encounter any issues, our dedicated customer service team is ready to assist you promptly.
Choose us as your reliable supplier for wholesale Spring Terminal Blocks. We offer competitive pricing, fast shipping, and exceptional customer service.
|
item
|
value
|
|
Place of Origin
|
Shanghai,China
|
|
Brand Name
|
Sk(Shangkai), yongxing
|
|
Model Number
|
YX122-016-03P
|
|
Type
|
Spring Terminal
|
|
Rated voltage
|
300V
|
|
Rated Current
|
10A
|
|
Contact Resistance
|
20mΩ
|
|
Insulation Resistance
|
>5000MΩ DC500V
|
|
Withstand Voltage
|
AC2000V/Min
|
|
Operating Temperature
|
-40℃~+150℃
|
|
Contact
|
Brass,Tin plated
|
|
Poles
|
2~16 poles
|
|
Certificate
|
CQC
|
Why Choose Our Spring Terminal Block?
Our Spring Terminal Block stands out for its durability, ease of use, and wide temperature range. Made with high-quality brass and tin-plated contacts, it ensures reliable connections even in harsh environments. The screwless design allows for quick and easy installations, saving you time and effort.
What Are the Key Features?
Key features include a rated voltage of 300V, a rated current of 10A, and an insulation resistance exceeding 5000MΩ at DC500V. It also withstands voltages up to AC2000V/Min and operates efficiently from -40℃ to +150℃.
Who Can Benefit from This Product?
This product is ideal for anyone needing secure and reliable electrical connections, including industrial machinery manufacturers, home appliance repairers, and DIY enthusiasts. As a wholesale supplier, we offer competitive pricing and fast shipping, making it a cost-effective choice for bulk purchases.
