Description
Our rocker switch boasts a mechanical life of 50,000 cycles and an electronic life of 10,000 cycles, ensuring long-lasting performance. With a contact resistance of ≤50mΩ and insulation resistance of ≥1000MΩ, it provides reliable electrical connections. The dielectric strength of 1500VAC for 1 minute ensures safety under high voltage conditions.
Available in multiple colors including Red, Yellow, Green, Black, Blue, Orange, White, and Gray, this switch can be customized to match your specific needs. As a factory supplier, we offer competitive pricing and bulk order discounts. Our dedicated after-sales service team is always ready to assist with any queries or issues.
Choose our SPST 2 Pin Rocker Switch for its superior quality, durability, and cost-effectiveness. Perfect for use in boats, automotive, industrial equipment, and more.
|
item
|
value
|
|
Place of Origin
|
Shanghai, China
|
|
Brand Name
|
SK(shangkai) Yongxing
|
|
Model Number
|
KCD3-11-CA1A-P-P-01
|
|
Max. Current
|
10(3)A
|
|
Max. Voltage
|
250V AC
|
|
Mechanical Life
|
50000 Cycles
|
|
Contact Resistance
|
≤50mΩ
|
|
Insulation Resistance
|
≥1000MΩ
|
|
Dielectric Strength
|
1500VAC 1 Minute
|
|
Electronic Life (cycles)
|
10,000
|
|
Certificate
|
CQC CE ROHS
|
|
Circuit
|
SPST
|
|
Dimension Code
|
A1 (21.7×15)
|
|
Contact Piece Code
|
A (4.8×0.8 standard)
|
|
Color
|
Red,Yellow,Green,Black,Blue,Orange,White,Gray
|
|
Function
|
On Off
|
Key Features and Advantages
Our SPST 2 Pin Rocker Switch stands out with its high current and voltage ratings, ensuring reliable performance in demanding applications. The durable gray housing and long mechanical life make it a cost-effective choice for bulk purchases.
Wide Range of Applications
Suitable for boats, automotive, and industrial equipment, this switch offers versatility and ease of use. Its multiple color options allow for customization to match specific design requirements.
Factory Direct Wholesale
As a factory supplier, we offer competitive pricing and bulk order discounts. Our dedicated after-sales service ensures a smooth purchasing experience and ongoing support.
