Description
|
item
|
value
|
|
Place of Origin
|
Shanghai, China
|
|
Brand Name
|
SK(shangkai) Yongxing
|
|
Model Number
|
KCD3-11-CB1B-B-G-01
|
|
Current Rating
|
10A
|
|
Voltage Rating
|
250V AC
|
|
Mechanical Life
|
50000 Cycles
|
|
Contact Resistance
|
≤50mΩ
|
|
Insulation Resistance
|
≥1000MΩ
|
|
Dielectric Strength
|
1500VAC 1 Minute
|
|
Electronic Life (cycles)
|
10,000
|
|
Certificate
|
CB ENEC17 ROHS
|
|
Circuit
|
SPST rocker switch
|
|
Dimension Code
|
B1 ( 21.4x15x15.2 , 19.3×13.2×12.9)
|
|
Contact Piece Code
|
B (8 length, 4.8×0.8 standard)
|
|
Actuator Color
|
Red,Yellow,Green,Black,Blue,Orange,White,Gray
|
|
Switch Function
|
On Off rocker switch
|
Why Choose Our SPST Mini Rocker Switch?
Our SPST Mini Rocker Switch stands out for its durability, reliability, and versatility. With a mechanical life of 50,000 cycles and an electronic life of 10,000 cycles, it ensures long-lasting performance. The compact size (21.4x15x15.2mm) makes it ideal for various applications where space is limited.
What Are the Key Features?
Key features include a current rating of 10A and a voltage rating of 250V AC, making it suitable for a wide range of electronic devices. It comes with UL, CB, ENEC17, and ROHS certifications, ensuring it meets the highest safety standards. Choose from multiple actuator colors to match your design needs.
How Can You Benefit from Our Factory-Direct Pricing?
As a factory direct supplier, we offer wholesale pricing on our SPST Mini Rocker Switch. This means you get high-quality products at competitive prices, without compromising on quality or service. Perfect for OEMs, resellers, and DIY enthusiasts, our switch is a cost-effective solution for your next project.
