Description
Key Specifications:
- Max. Current: 6A
- Max. Voltage: 250V AC
- Mechanical Life: 10,000 Cycles
- Contact Resistance: ≤50mΩ
- Insulation Resistance: ≥100MΩ
- Dielectric Resistance: 1500V
- Operating Temperature: T125
- IP Level: IP40
- Color: Black
Product Advantages:
- Durable construction with a mechanical life of 10,000 cycles, ensuring long-lasting performance.
- Low contact resistance (≤50mΩ) and high insulation resistance (≥100MΩ) for reliable electrical connections.
- Wide operating temperature range (T125), suitable for various environments.
- Versatile application in home appliances, electronics, and electrical instrumentation.
Why Choose Us?
- We are a factory supplier, offering competitive wholesale prices and direct sales.
- High-quality products with strict quality control measures.
- Excellent customer service and after-sales support.
|
item
|
value
|
|
Place of Origin
|
Shanghai,China
|
|
Brand Name
|
SK(shangkai) yongxing
|
|
Model Number
|
RS1-15G-AEH-BBA
|
|
Max. Current
|
6A
|
|
Max. Voltage
|
250V AC
|
|
Mechanical Life
|
10000 Cycles
|
|
Contact Resistance
|
≤50mΩ
|
|
Insulation Resistance
|
≥100MΩ
|
|
Dielectric Resistance
|
1500V
|
|
Electronic Life
|
10,000 cycles
|
|
Operating Temperature
|
T125
|
|
Scope of Application
|
Home appliances,electronics, electrical instrumentation
|
|
Circuit
|
4 momentary position
|
Why Choose Our T125 Rotary Switch?
Our T125 Rotary Switch is designed for durability and reliability, with a mechanical life of 10,000 cycles. It offers low contact resistance and high insulation resistance, ensuring stable electrical connections. Perfect for a wide range of home appliances, electronics, and electrical instrumentation.
What Are the Key Specifications?
Key specifications include a maximum current of 6A, maximum voltage of 250V AC, and an operating temperature of T125. It also features an IP40 rating and comes in a sleek black color.
Why Buy from Us as a Factory Supplier?
As a factory supplier, we offer competitive wholesale prices and direct sales, eliminating the middleman. Our products undergo strict quality control measures, ensuring you receive high-quality switches every time. Plus, we provide excellent customer service and after-sales support.
