Description
|
item
|
value
|
|
Place of Origin
|
Shanghai, China
|
|
Brand Name
|
SK(shangkai) Yongxing
|
|
Model Number
|
KCD7-11-CF1B-B-B
|
|
Current Rating
|
6A
|
|
Voltage Rating
|
250V AC
|
|
Mechanical Life
|
50000 Cycles
|
|
Contact Resistance
|
≤50mΩ
|
|
Insulation Resistance
|
≥1000MΩ
|
|
Dielectric Strength
|
1500VAC 1 Minute
|
|
Electronic Life (cycles)
|
10,000
|
|
Certificate
|
CQC CE ROHS
|
|
Circuit
|
SPST
|
|
Dimension Code
|
F1 (21.2×23.3×9.6, 19.3×21.5×6.4)
|
|
Contact Piece Code
|
B (8 length, 4.8×0.8 standard)
|
|
Lamp voltage
|
6v/12v/24v/110v/220v
|
Why Choose Our Waterproof Black Rocker Switch?
Our Waterproof Black Rocker Switch stands out for its exceptional durability and safety features. With an IP65 rating, it offers superior protection against water and dust, making it ideal for various environments. The switch's 50,000 mechanical life cycles and 10,000 electronic life cycles ensure long-lasting performance, reducing the need for frequent replacements. Additionally, its compliance with CQC, CE, and ROHS standards guarantees safety and reliability.
What Are the Key Specifications?
The switch has a maximum current of 6A and a voltage rating of 250V AC, making it suitable for a wide range of applications. Its SPST circuit and precise dimensions (F1: 21.2x23.3x9.6, 19.3x21.5x6.4 mm) ensure easy installation and compatibility. The contact resistance is ≤50mΩ, and the insulation resistance is ≥1000MΩ, providing optimal electrical performance.
What Are the Advantages of Buying from Us?
As a factory supplier, we offer competitive wholesale prices and excellent after-sales service. Our switches are rigorously tested to ensure they meet the highest quality standards. With multiple lamp voltage options (6v/12v/24v/110v/220v) and a wide operating temperature range (0~55℃), our switches are versatile and suitable for a variety of applications. Choose us for reliable, high-quality switches at unbeatable prices.
