Description
|
item
|
value
|
|
Place of Origin
|
Shanghai, China
|
|
Brand Name
|
SK(shangkai) Yongxing
|
|
Model Number
|
KCD3-11N-FB1B-B-R-01
|
|
Current Rating
|
10(3)A
|
|
Voltage Rating
|
250V AC
|
|
Mechanical Life
|
50000 Cycles
|
|
Contact Resistance
|
≤50mΩ
|
|
Insulation Resistance
|
≥1000MΩ
|
|
Dielectric Strength
|
1500VAC 1 Minute
|
|
Electronic Life (cycles)
|
10,000
|
|
Certificate
|
CB ENEC17 ROHS
|
|
Circuit
|
SPST
|
|
Dimension Code
|
B1 (21.4x15x15.2 , 19.3×13.2×12.9)
|
|
Contact Piece Code
|
B (8 length, 4.8×0.8 standard)
|
|
Lamp voltage
|
6V/12V/24V/110V/220V/others
|
|
Switch Function
|
On Off Illuminated Waterproof IP65
|
Why Choose Our Waterproof LED Rocker Switch?
Our Waterproof LED Rocker Switch is designed to withstand harsh environments, making it perfect for marine and outdoor applications. With its IP65 waterproof rating, it ensures reliable performance even in wet conditions. The illuminated design provides clear visibility, enhancing user experience.
What Makes Our Switch Stand Out?
Our switch offers a long mechanical life of 50,000 cycles and an electronic life of 10,000 cycles, ensuring durability and cost-effectiveness. As a direct factory supplier, we provide competitive wholesale prices and excellent after-sales service, making our product a top choice for bulk purchases.
What Are the Key Features of Our Switch?
Our switch supports current ratings of 6A/10A at 250Vac, with lamp voltages available in multiple options. It is certified with CB, ENEC17, and ROHS, meeting international quality standards. Choose our Waterproof LED Rocker Switch for reliable performance and peace of mind.
