Description
Product Specifications:
- Brand Name: Sk (Shangkai) Yongxing
- Model Number: LA133-A1.Y2S-K20
- Protection Level: IP40, IP65, IP67
- Max. Current: 10A
- Max. Voltage: 660 VAC
- Rated Insulation Voltage: 660V AC
- Rated Thermal Current: 10A
- Max. Insulation Voltage: 2500 V/min
- Usage Category: AC-15, DC-13
- Mechanical Life: 1,000,000 cycles
- Operation Frequency: 1200 cycles/h
- Electrical Life for AC-15: 600,000 cycles
- Electrical Life for DC-13: 250,000 cycles
- Mounting Hole Size: 22mm Diameter
- Material: PA66
- Color: Red
- Head Type: Round Head
- Terminal Type: Plug Terminal
- Illuminated Type: Full Illuminated
- LED: Yes
- Smart Feature: No
Product Advantages:
- High mechanical and electrical life ensures long-term reliability.
- Multiple protection levels (IP40, IP65, IP67) for versatile use.
- Factory direct pricing and wholesale availability.
- Durable PA66 material construction.
After-Sales Service: We offer comprehensive after-sales support, including technical assistance and warranty services, ensuring your satisfaction with our product.
|
item
|
value
|
|
Place of Origin
|
Shanghai,China
|
|
Brand Name
|
Sk(shangkai) yongxing
|
|
Model Number
|
LA133-A1.Y2S-K20
|
|
Protection Level
|
IP40 IP65 IP67
|
|
Max. Current
|
10A
|
|
Max. Voltage
|
660 VAC
|
|
Rated Insulation Voltage
|
660v ac
|
|
Rated Thermal Current
|
10A
|
|
Max.insulation voltage
|
2500 V/min
|
|
Usage Category
|
AC-15 DC-13
|
|
Mechanical Life
|
1000,000
|
|
Operation frequency
|
1200 cycles/h
|
|
Electrical life for AC-15
|
600000 cycles
|
|
Electrical life for DC-13
|
250000 cycles
|
|
Mounting Hole Size
|
22mm Diameter
|
Why Choose Our Yongxing 2-Position Self-Locking Key Switch?
Our Yongxing 2-Position Self-Locking Key Switch stands out with its high mechanical and electrical life, ensuring long-term reliability and durability. The multiple protection levels (IP40, IP65, IP67) make it suitable for a wide range of applications, from electric to home appliances. As a factory direct supplier and wholesaler, we offer competitive pricing without compromising on quality.
Key Features and Benefits
The switch's PA66 material construction provides excellent strength and resistance to wear and tear. Its full illuminated design enhances visibility, making it easier to operate in low-light conditions. With a rated thermal current of 10A and a max. insulation voltage of 2500 V/min, this switch is designed to handle demanding electrical loads efficiently.
After-Sales Support and Warranty
We stand behind our product with comprehensive after-sales support, including technical assistance and warranty services. Our goal is to ensure your complete satisfaction with our Yongxing 2-Position Self-Locking Key Switch, making it a wise choice for your electrical and home appliance needs.
