Yongxing AD10 Electronic Push Button Switch | Wholesale Supplier | Factory-Direct Quality

Description

Discover the Yongxing AD10 Series Electronic Push Button Switch, a top-tier choice for medical equipment and various industrial applications. As a factory-direct supplier and wholesaler, we offer competitive pricing and reliable quality. This switch boasts a 3A maximum current and 250V maximum voltage, ensuring robust performance. It comes with an integrated LED, providing full illumination for easy visibility. The switch is constructed from durable PA66 material, featuring a square or round head design and pin terminals for versatile installation. With an IP40 rating, it offers reliable protection against dust and splashes. The 1NO1NC switch combination, along with low contact resistance (≤50mΩ) and high insulation resistance (≥100mΩ), ensures efficient and safe operation. The switch has an electrical life of 25,000 times and a mechanical life of 50,000 times, making it highly durable. Operating within a temperature range of -5°C to +75°C, it is suitable for a wide range of environments. Available in green, this 10mm switch is perfect for electric, home appliance, and industrial control applications. Choose Yongxing for quality, reliability, and value.

Electronic component product image for cross-border e-commerceHigh-quality electronic device image for e-commerceElectronic gadget product display imageElectronic part product image for e-commerceElectronic accessory product display imageElectronic product image for cross-border e-commerceElectronic component display image for e-commerce


Why Choose Yongxing AD10 Electronic Push Button Switch?

The Yongxing AD10 Electronic Push Button Switch stands out for its high-quality construction, reliable performance, and versatile applications. With a 3A maximum current and 250V maximum voltage, it is suitable for a wide range of electrical and industrial needs. The integrated LED provides full illumination, making it easy to see and operate in various lighting conditions.

What Makes Yongxing AD10 Different?

Unlike other switches on the market, the Yongxing AD10 is constructed from durable PA66 material, ensuring long-lasting use. It features a square or round head design and pin terminals for easy installation. With an IP40 rating, it offers reliable protection against dust and splashes. The switch's low contact resistance and high insulation resistance ensure efficient and safe operation.

Where Can Yongxing AD10 Be Used?

The Yongxing AD10 Electronic Push Button Switch is perfect for medical equipment, electric applications, home appliances, and industrial control systems. Its robust design and reliable performance make it an ideal choice for any application requiring a durable and efficient switch. Choose Yongxing for quality, reliability, and value.

Push Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch Customized

Additional information

Max. Current

3A

Max. Voltage

250V

Place of Origin

Shanghai, China

Brand Name

Yongxing

Model Number

AD10-113L24D-G

LED

Yes

Application

Electric, Home Appliance, Industrial Control

Material

PA66

Structure

Electronic

Head Type

Square Head, Round Head

Terminal Type

Pin terminal

Whether the smart

NO

illuminated Type

full illuminated

IP level

IP40

Switch Combination

1NO1NC

Contact Resistance

≤50mΩ

Insulation Resistance

≥100mΩ

Dielectric Strength

1500V

Electrical Life (Alternate)

25000 Times

Mechanical Life (Alternate)

50000 Times

Operating Temperature

-5° T +75°
