Description
Our switch features a robust design with a max. rating of 3A 250VAC, ensuring reliable performance even under demanding conditions. It comes with a choice of 1NO1NC or 2NO2NC switch combinations, allowing for flexible configuration. With a mechanical life of up to 200,000 operations for momentary use and 50,000 for alternate use, it offers exceptional durability. The electrical life is also impressive, with 50,000 operations for momentary and 25,000 for alternate use.
One of the standout features of our push button switch is its low contact resistance of less than 50mΩ, ensuring minimal power loss and efficient operation. Additionally, it boasts an insulation resistance of over 100MΩ and a dielectric strength of 1500V, providing excellent electrical safety. The operating temperature range of -5℃ to +75℃ makes it suitable for a wide variety of environments.
We take pride in our manufacturing capabilities, with an independent plant, injection workshop, and advanced experimental equipment. Our team of over 60 senior engineers ensures that every switch meets our high standards of quality. All workshops adhere to 5S and 5m management standards, guaranteeing consistent production excellence.
As a factory-direct supplier, we offer customization options for bulk orders, allowing you to tailor the switch to your specific requirements. Our switches are CQC and CE certified, providing you with peace of mind regarding their safety and compliance. Choose Yongxing for reliable, high-quality push button switches at wholesale prices.
|
max.rating cnrrent&voltage
|
3a 250vac
|
||
|
contact resistance
|
<50mΩ
|
||
|
insulation resistance
|
>100mΩ
|
||
|
dielectrice resistance
|
1500V
|
||
|
mechanical life
|
momentary 200000,alternate 50000
|
||
|
electronic life
|
momentary 50000,alternate 25000
|
||
|
operating temperature
|
-5℃ to +75℃
|
||
|
CQC,CE
|
Why Choose Our Yongxing 12mm Momentary Push Button Switch?
Our Yongxing 12mm Momentary Push Button Switch stands out for its robust design, high-quality materials, and exceptional durability. With a max. rating of 3A 250VAC, it ensures reliable performance in demanding industrial environments. The switch's low contact resistance and high insulation resistance contribute to efficient operation and electrical safety.
What Are the Key Features of Our Push Button Switch?
Key features include a choice of 1NO1NC or 2NO2NC switch combinations, a mechanical life of up to 200,000 operations for momentary use, and an electrical life of 50,000 operations. It also boasts a wide operating temperature range of -5℃ to +75℃, making it suitable for various applications.
Can We Customize the Push Button Switch for Our Needs?
Yes, as a factory-direct supplier, we offer customization options for bulk orders. Whether you need specific switch combinations, labeling, or packaging, we can tailor the push button switch to meet your exact requirements. Our team of senior engineers is ready to assist you in creating the perfect solution for your industrial needs.
