Description
Introducing our Yongxing Factory Wholesale 16A 2-Pin Rocker Switch, a high-quality electrical component designed for medical appliances and household meters. This switch boasts a robust mechanical life of 100,000 cycles and an electronic life of 10,000 cycles, ensuring long-lasting reliability. With CQC, CE, and ROHS certifications, it meets international safety standards. The switch features a maximum current of 16A and a maximum voltage of 250VAC, making it suitable for a wide range of applications. Its compact design with a panel cutout of 28.4*10.7mm and standard 6.3×0.8mm terminals ensures easy installation. The white housing with a green actuator not only adds a touch of style but also provides clear ON/OFF marking for user convenience. Made from durable PA66 material, this switch offers excellent insulation resistance and contact resistance. As a factory supplier, we offer competitive wholesale prices and excellent after-sales service. Choose Yongxing for reliable, high-quality electrical switches.
|
item
|
value
|
|
Certification
|
CQC CE ROHS
|
|
Model Number
|
KCD1-11-CA6C-W-G-03(279)
|
|
Max. Current
|
16A
|
|
Max. Voltage
|
250VAC
|
|
Mechanical Life
|
100,000 cycles
|
|
Electronic Life
|
10,000 cycles
|
|
Dielectric Strength
|
1,500VAC,1min
|
|
Contact Resistance
|
≤50mΩ
|
|
Insulation Resistance
|
≥1,000MΩ
|
|
Operating Temperature
|
T85
|
|
Circuit
|
SPST ON-OFF 2Pin
|
|
Panel cutout
|
28.4*10.7mm
|
|
Terminal
|
6.3×0.8 mm standard
|
|
Color
|
White housing, green actuator
|
|
Marking
|
white ON OFF marking
|
|
Material
|
PA66
|
Why Choose Our 16A Rocker Switch?
Our 16A Rocker Switch stands out with its high mechanical and electronic life, ensuring long-lasting reliability. It's CQC, CE, and ROHS certified, meeting international safety standards. Perfect for medical appliances and household meters, it offers a compact design with easy installation.
What Are the Key Features?
Key features include a maximum current of 16A, a maximum voltage of 250VAC, and a durable PA66 material construction. The switch also features clear ON/OFF marking and a compact panel cutout for easy integration into various devices.
Why Buy from Yongxing?
As a factory supplier, we offer competitive wholesale prices and excellent after-sales service. Our switches are known for their high quality and reliable performance, making them the ideal choice for your electrical needs.
