Description
Introducing the Yongxing 16A 250V Rocker Switch, a high-quality electrical component designed for a wide range of applications. This switch, with its sleek black housing and actuator, is not only aesthetically pleasing but also highly functional. As a factory-direct supplier, we offer wholesale pricing on this durable switch, which boasts a mechanical life of 100,000 cycles and an electronic life of 10,000 cycles. The switch is certified with CQC, CE, and ROHS, ensuring its safety and reliability. It features a SPST ON-OFF 2Pin circuit, a panel cutout of 28×11 mm, and a 6.3×0.8 mm standard terminal. The contact resistance is ≤50mΩ, and the insulation resistance is ≥1,000MΩ, making it suitable for use in various environments with an operating temperature of T85. The switch is made of PA66 material, known for its durability and heat resistance. Its IP level is IP65 and IP41, providing protection against dust and water. Whether you’re looking for a switch for your car, industrial equipment, or electric appliances, this Yongxing Rocker Switch is the perfect choice. With our factory-direct pricing and excellent customer service, you can trust that you’re getting a high-quality product at a great price.
|
item
|
value
|
|
Certification
|
CQC CE ROHS
|
|
Model Number
|
KCD1-11-CA1A-B-B-03
|
|
Max. Current
|
16A
|
|
Max. Voltage
|
250VAC
|
|
Mechanical Life
|
100,000 cycles
|
|
Electronic Life
|
10,000 cycles
|
|
Dielectric Strength
|
1,500VAC,1min
|
|
Contact Resistance
|
≤50mΩ
|
|
Insulation Resistance
|
≥1,000MΩ
|
|
Operating Temperature
|
T85
|
|
Circuit
|
SPST ON-OFF 2Pin
|
|
Panel cutout
|
28×11 mm
|
|
Terminal
|
6.3×0.8 mm standard
|
|
Color
|
Black housing, black actuator
|
|
Marking
|
white ON OFF
|
|
Material
|
PA66
|
Key Features
The Yongxing 16A 250V Rocker Switch stands out with its high mechanical and electronic life cycles, ensuring long-lasting performance. Its SPST ON-OFF 2Pin circuit and 28x11 mm panel cutout make it versatile for various applications.
Durable Construction
Made of PA66 material, this switch is built to withstand harsh conditions. Its IP65 and IP41 ratings provide excellent protection against dust and water, making it suitable for both indoor and outdoor use.
Factory Wholesale Pricing
As a factory-direct supplier, we offer competitive wholesale pricing on this high-quality switch. With our excellent customer service and fast shipping, you can trust that you're getting a great deal on a reliable product.
