Description
Key Features:
– Material: High-quality brass with tin plating for contacts, and PA66 housing with UL94V-0 rating for durability and safety.
– Operating Temperature: -40°C to +150°C, ensuring reliable performance in extreme conditions.
– Electrical Performance: Low contact resistance (20mΩ), high insulation resistance (>5000MΩ DC500V), and withstanding voltage up to AC2000V/1Min.
– Certifications: CQC UL certified, ensuring quality and compliance with international standards.
Our factory-direct pricing and wholesale availability make this terminal block an excellent choice for bulk purchases. We offer competitive prices and reliable after-sales service, ensuring your satisfaction. Choose Yongxing for quality, reliability, and value.
| Material | |
| Contact | Brass, Tin Plated |
| Housing | PA66 ,UL94V-0 |
| Color | Green pa66 terminal connector |
| Environmental | |
| Operating temperature | -40°C ~ 150°C |
| Short-time temperature | +250°C for 5 sec |
| Electrical | |
| Rated voltage | 300V connector blocks |
| Rated current | 16A 2 pins connector |
| Contact resistance | 20mΩ |
| Insulation resistance | >5000MΩ DC500V |
| Withstanding voltage | AC2000V/1Min |
Why Choose Our 16A 6-Pin PCB Terminal Block?
Our 16A 6-Pin PCB Terminal Block stands out for its durability, reliability, and performance. Made with high-quality brass contacts and PA66 housing, it ensures long-lasting use even in harsh environments. The push-in connection method simplifies installation, saving you time and effort.
What Are the Key Advantages?
With a rated voltage of 300V and a rated current of 16A, this terminal block meets the demands of industrial and automotive applications. Its high insulation resistance and low contact resistance guarantee safe and efficient electrical connections. Plus, our factory-direct pricing and wholesale availability make it a cost-effective choice.
How Does It Compare to Other Products?
Unlike many competitors, our terminal block is CQC UL certified, ensuring it meets the highest quality and safety standards. Its wide operating temperature range (-40°C to +150°C) and ability to withstand high voltages make it superior to similar products on the market. Choose Yongxing for a terminal block that delivers on performance and value.
