Description
Product Specifications:
- Max. Current: 3A
- Max. Voltage: 250V
- Material: Durable plastic
- Structure: Electronic
- Head Type: Round Head
- Terminal Type: Plug Terminal
- IP Level: IP65 (with IP44 protection level also available)
- Switch Combination: 1NO1NC
- Color: Bright Red for high visibility
- Size: 16mm
- Operation Type: Self-locking
- Electrical Life: 25,000 cycles
- Contact Resistance: ≤50mΩ
- Insulation Resistance: ≥100mΩ
Product Advantages:
- Customization: We offer customization services to meet your specific requirements, ensuring the switch fits perfectly into your machinery.
- Factory Direct: As a factory, we can provide competitive wholesale prices and ensure high-quality production standards.
- Advanced Facilities: Our company boasts an independent plant, injection workshop, and advanced experimental equipment, ensuring top-notch quality control.
- Experienced Team:
- 5S and 5M Management: All our workshops adhere to strict 5S and 5M management standards, ensuring efficiency and quality.
With over 60 senior engineers, we have the expertise to develop and produce switches that exceed your expectations.
After-Sales Service: We stand behind our products with excellent after-sales service, including technical support and warranty coverage.
Choose Yongxing for your emergency stop switch needs and experience the difference in quality and service.
|
Max.Rating Current & Voltage(Resistive Load) |
3A/250V |
|
Contact Resistance |
≤50mΩ |
|
Insulation Resistance |
≥100MΩ |
|
Dielectric Strength |
1500V |
|
Electronic Life(cycles) |
25000 |
|
Mechanical Life(cycles) |
50000 |
|
Operating temperature |
-5°c~+75°c |
|
IP code |
IP44 |
Why Choose Our Emergency Stop Switch?
Our emergency stop switch is designed with safety and reliability in mind. The bright red color ensures high visibility, making it easy to locate in an emergency. The self-locking operation type ensures that once activated, the switch remains in the off position until manually reset, providing an extra layer of safety.
What Makes Our Switch Stand Out?
Unlike many other switches on the market, our product is factory-direct, meaning we can offer competitive wholesale prices without compromising on quality. With certifications like UL, CE, and ENEC, you can be assured that our switch meets the highest international standards.
How Can We Help You?
Whether you need a standard switch or a customized solution, our experienced team is here to help. We offer technical support, warranty coverage, and excellent after-sales service to ensure your satisfaction. Choose Yongxing for your emergency stop switch needs and experience the difference in quality and service.
