Description
|
item
|
value
|
|
Certification
|
CQC CE ROHS
|
|
Model Number
|
KCD1-11-CA5A-B-B-01/850℃-30A (259)
|
|
Max. Current
|
16A
|
|
Max. Voltage
|
250VAC
|
|
Mechanical Life
|
100,000 cycles
|
|
Electronic Life
|
10,000 cycles
|
|
Dielectric Strength
|
1,500VAC,1min
|
|
Contact Resistance
|
≤50mΩ
|
|
Insulation Resistance
|
≥1,000MΩ
|
|
Operating Temperature
|
T85
|
|
Circuit
|
SPST ON-OFF 2Pin
|
|
Panel cutout
|
27.7*10.7mm
|
|
Terminal
|
6.3×0.8 mm standard
|
|
Color
|
Black housing, black actuator
|
|
Marking
|
white I O
|
|
Material
|
PA66
|
Why Choose Our Yongxing KCD Rocker Switch?
Our Yongxing KCD Rocker Switch stands out for its high durability and reliability, with a mechanical life of 100,000 cycles and an electronic life of 10,000 cycles. It is designed to handle a maximum current of 16A and a maximum voltage of 250VAC, making it suitable for a wide range of applications, including cars, industrial machinery, and electric equipment. The switch's sleek black housing and actuator, along with white I/O markings, ensure easy identification and operation.
What Are the Key Features of Our Switch?
Our switch is certified by CQC, CE, and ROHS, guaranteeing its safety and compliance with international standards. It has a dielectric strength of 1,500VAC for 1 minute, a contact resistance of ≤50mΩ, and an insulation resistance of ≥1,000MΩ. The switch operates at a temperature of T85, making it suitable for various environments. Its compact design, with a panel cutout size of 27.7*10.7mm and a 6.3x0.8mm standard terminal, allows for easy installation.
Why Buy from Us as a Supplier and Wholesaler?
As a direct supplier and wholesaler, we offer competitive pricing and bulk order discounts on our Yongxing KCD Rocker Switch. We ensure high-quality products and excellent customer service, making your purchasing experience smooth and hassle-free. Choose us for your electrical switch needs and enjoy the benefits of factory-direct pricing and reliable supply.
