Description
Key Specifications:
- Max. Current & Voltage: 3A, 250V AC
- Switch Combination: 2NO2NC
- Operation Type: Self-locking
- Mounting Hole Size: 17x17mm
- Electrical Life: 10,000 Cycles
- Mechanical Life: 50,000 Cycles
- IP Level: IP40
- LED Indicator: Yes
Advantages:
- Durable construction ensures long-lasting performance.
- Self-locking operation type provides convenience and safety.
- Illuminated design enhances visibility in low-light conditions.
- Competitive pricing as a direct factory supplier.
Applications: Our KD2 Push Button Switch is widely used in industrial control systems, machinery, automation equipment, and more. Its reliability and versatility make it a preferred choice for professionals.
After-Sales Service: We offer comprehensive after-sales service, including technical support and warranty coverage. As a factory supplier, we ensure fast delivery and competitive pricing for wholesale orders.
|
contact resistance
|
≤50MΩ
|
electronic life（cycles）
|
10000
|
|
insulation resistance
|
≥100MΩ
|
mechanical life（cycles）
|
50000
|
|
dielectric strength
|
1500V
|
operating temperature
|
25T55
|
|
IP code
|
IP40
|
max.rating current & voltage
|
3A 250V AC
|
Why Choose Our KD2 Push Button Switch?
Our KD2 Push Button Switch stands out with its 8-pin design, 2NO2NC configuration, and self-locking operation. It's perfect for industrial control systems, offering durability and reliability.
What Makes Our Product Unique?
As a factory supplier, we ensure competitive pricing and fast delivery. The illuminated design enhances visibility, and the self-locking feature provides added safety and convenience.
What Applications Is It Suitable For?
Our switch is widely used in machinery, automation equipment, and more. Its versatility and reliability make it a top choice for professionals seeking high-quality components.
