Yongxing Factory Wholesale KW11 Micro Switch – UL & CQC Certified

500 - 1,999  pieces
$0.24

2,000 - 4,999  pieces
$0.21

>= 5,000  pieces
$0.19

0 reviews

Factory Wholesale KW11 Micro Switch – High Quality, Reliable, UL & CQC Certified

Description

Introducing our Yongxing Factory Direct KW11 Micro Switch, a high-quality, reliable component for electric appliances. As a leading supplier and wholesaler, we offer this micro switch at competitive prices, ensuring you get the best value for your money. Our KW11 model boasts a long mechanical life of 100,000 times and an electrical life of 50,000 cycles, making it ideal for industrial, electric power, and household applications. With a maximum current of 5A and a maximum voltage of 250V, it can handle a wide range of electrical loads. The switch is made of durable plastic material, ensuring its longevity and reliability. It comes with an IP40/IP65 protection level, making it resistant to dust and water. Our micro switch is UL and CQC certified, guaranteeing its safety and quality. Choose Yongxing for your micro switch needs and enjoy our factory-direct prices and excellent after-sales service.
Product Model
KW11-12-B
Electronic Life(cycles)
50000

Electronic component device for cross-border e-commerceElectronic gadget product for cross-border e-commerce


Why Choose Our KW11 Micro Switch?

Our KW11 Micro Switch stands out due to its long mechanical life of 100,000 times and an electrical life of 50,000 cycles, ensuring durability and reliability. It is UL and CQC certified, guaranteeing safety and quality, making it a trusted choice for various applications.

What Are the Key Features?

Key features include a maximum current of 5A and a maximum voltage of 250V, suitable for a wide range of electrical loads. The switch is made of durable plastic material and has an IP40/IP65 protection level, offering resistance to dust and water.

Why Buy from Yongxing?

As a factory supplier and wholesaler, we offer competitive prices and excellent after-sales service. Our KW11 Micro Switch is of high quality and reliability, making it the ideal choice for your electric appliance needs.

Push Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch Customized

Additional information

Whether the smart

NO

Max. Current

5A

Max. Voltage

250V

Place of Origin

Shanghai, China

Brand Name

Yongxing

Model Number

KW11-12-B

Application

Industrial, electric power, households

Material

plastic

Mechanical Life

100000 times

Circuit

SPDT

IP level

IP40, IP65

Product name

Micro switch

Color

black gray

Contact Resistance

≤50mΩ

Dielectric Strength

1500V

Operating temperature

-25 ~125℃

Certification

CQC,ENEC

Protection Level

IP40
