Yongxing Factory Wholesale MA16 3A 250V Metal Key Switch | IP65 Waterproof

500 - 1,999  pieces
$4.32

2,000 - 4,999  pieces
$4.30

>= 5,000  pieces
$4.25

0 reviews

Yongxing Factory Wholesale MA16 3A 250V Metal Key Switch | IP65 Waterproof | Buy Direct & Save!

Description

Discover our Yongxing Factory Wholesale MA16 3A 250V Metal Key Switch, a high-quality switch designed for a wide range of applications. This switch features a robust metal construction with stainless steel and brass shell materials, ensuring durability and longevity. With a maximum current of 3A and a maximum voltage of 250V, it is suitable for instruments, home appliances, industrial control, and electric equipment. The switch offers a 180° rotation range and a mechanical life of 50,000 times, providing reliable performance. Its IP65 waterproof rating makes it ideal for use in wet environments, while the low contact resistance (≤50mΩ) and high insulation resistance (≥100MΩ) ensure efficient and safe operation. The switch comes with pin terminals and is available in various colors with light options, including red, yellow, green, blue, and white. Choose from flat, high, or ball head types to suit your needs. Certified by CQC and CE, this switch meets high-quality standards. As a factory supplier, we offer competitive wholesale prices and excellent after-sales service. Order now and experience the difference!

Electronic component product image for cross-border e-commerce


Why Choose Our MA16 Metal Key Switch?

Our MA16 Metal Key Switch stands out with its IP65 waterproof rating, ensuring reliable operation in wet environments. The durable stainless steel and brass construction, combined with a mechanical life of 50,000 times, guarantees long-lasting performance. Perfect for instruments, home appliances, and industrial control, this switch offers a 3A 250V capacity and low contact resistance for efficient operation.

What Makes Our Switch Different?

Unlike other switches on the market, our MA16 Metal Key Switch features a 180° rotation range and is available in multiple colors with light options. It is also certified by CQC and CE, ensuring high-quality standards. As a factory supplier, we offer competitive wholesale prices and excellent after-sales service, making it a cost-effective choice for your needs.

Where Can You Use Our MA16 Metal Key Switch?

Our MA16 Metal Key Switch is ideal for a wide range of applications, including instruments, home appliances, industrial control, and electric equipment. Its robust construction and reliable performance make it suitable for both residential and commercial use. Order now and experience the difference in quality and service!

Push Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch Customized

Additional information

Whether the smart

NO

Max. Current

3A

Max. Voltage

250V

Place of Origin

Shanghai, China

Brand Name

Yongxing

Model Number

MA16

Application

Instrument, Home Appliances, Industrial Control, electric equipment

Material

Metal

Terminal Type

Pin terminal

Rotation Range

180°

Mechanical Life

50000 times

IP level

IP65

Contact Resistance

≤50mΩ

Insulation Resistance

≥100MQ

Withstand voltage

1500VAC 50Hz 1min

Electrical life

25000 Times

Mechanical life

50000 Times

Working ambient temperature

-25℃~55℃

Shell material

stainless steel, brass

Color with light

red/yellow/green/blue/white

Head type

flat/high/ball head

Certification

CQC, CE
