Description
Yongxing Factory Direct Supply Micro Switch
As a leading micro switch supplier and factory in Shanghai, China, Yongxing offers high-quality, customizable micro switches at wholesale prices. Our KW11 model micro switch is designed for household applications, featuring a robust plastic construction, SPST 3-pin function, and waterproof IP40 rating. With a contact resistance of ≤50mΩ, insulation resistance of ≥100mΩ, and dielectric strength of 1500V, it ensures reliable performance. The switch operates within a wide temperature range of -25℃ to +125℃ and has a mechanical and electrical life of 50,000 cycles, making it ideal for long-term use.
Our factory is equipped with independent plants, injection molding workshops, and advanced experimental equipment. With over 60 senior engineers and 5S management implemented in all workshops, we guarantee top-notch quality and efficiency. Customization is available for bulk orders, allowing you to tailor the switch to your specific needs. Contact us today to discuss your requirements and benefit from our factory-direct pricing and excellent customer service.
| Contact Resistance | ≤50mΩ |
| Insulation Resistance | ≥100mΩ |
| Dielectric Strength | 1500V |
| Electronic Life | 50,000 cycles |
| Operating Temperature | -25℃~+125℃ |
| Rating Current & Voltage | 5A/250VAC |
| Contact Resistance | ≤50mΩ |
| Insulation Resistance | ≥100mΩ |
| Dielectric Strength | 1,500V |
| Electronic Life | 50,000 cycles |
| Operating temperature | -25℃~+125℃ |
| Rating current&voltage | 5A/250VAC |
Why Choose Yongxing Micro Switch?
Yongxing micro switches are renowned for their durability, reliability, and customization options. With a factory-direct supply, we offer competitive wholesale prices, ensuring you get the best value for your money. Our switches are designed to withstand harsh environments, thanks to their waterproof IP40 rating and wide operating temperature range.
Key Features
Our KW11 model micro switch features a contact resistance of ≤50mΩ, insulation resistance of ≥100mΩ, and dielectric strength of 1500V, ensuring optimal performance. With a mechanical and electrical life of 50,000 cycles, it's built to last, reducing maintenance costs and downtime.
Customization & Support
At Yongxing, we understand that every customer has unique needs. That's why we offer customization options for bulk orders, allowing you to tailor the switch to your specific requirements. Our dedicated customer service team is always on hand to provide assistance and ensure your satisfaction.
