Description
|
Certification
|
CE,CQC,CCC,TUV
|
|
Whether the smart
|
NO
|
|
Place of Origin
|
Zhejiang,China
|
|
Brand Name
|
Yongxing
|
|
Model Number
|
KCD1-11N-CF1B-B-R-0AC
|
|
Max. Current
|
16A
|
|
Max. Voltage
|
250V AC
|
|
Mechanical Life
|
10000
|
|
Product Name
|
Illuminated Single Pole Single Throw Rocker Switch Point Lamp
|
|
Function
|
Single pole single throw
|
|
Insulation Resistance
|
≥1000MΩ
|
|
Contact Resistance
|
≤50mΩ
|
|
Lamp color
|
Red
|
|
Operating temperature
|
T55 T85 T125
|
|
Pins
|
3 Pins
|
|
Terminal
|
3 Terminals
|
Why Choose Our Waterproof Rocker Switch?
Our Yongxing Factory Wholesale Waterproof Rocker Switch is designed to withstand harsh environments, thanks to its IP65 and IP41 waterproof ratings. This makes it ideal for outdoor or wet conditions, ensuring safety and reliability. The illuminated feature provides clear visibility, even in low-light conditions, enhancing user experience.
What Are the Key Specifications?
This switch offers a max current of 16A and a max voltage of 250V AC, making it suitable for a wide range of electric equipment. With 3 pins and 3 terminals, it's easy to install and integrate into your systems. The mechanical life of 10000 cycles ensures long-term durability.
Why Buy from Yongxing Factory?
As a factory supplier, we offer competitive wholesale prices without compromising on quality. Our products undergo rigorous testing to ensure they meet international standards. With excellent after-sales service, you can trust Yongxing for all your rocker switch needs.
