Description
Product Specifications:
– Max. Current: 4A
– Max. Voltage: 250V
– Material: PA66
– Size: 16MM
– Color: White
– Structure: Electronic
– Head Type: Round Head
– Terminal Type: Pin terminal
– Switch Combination: 1NO
– Contact Resistance: ≤50mΩ
– Insulation Resistance: 100MΩ
– Dielectric Strength: 1500V
– Electrical Life: 10,000 Times
– Mechanical Life: 50,000 Times
– Working Temperature: -25°C to +55°C
– Certification: CQC CE
Product Advantages:
1. **Durable Material**: Made from PA66, a high-strength and heat-resistant material, ensuring long-lasting performance.
2. **High Electrical Life**: With an electrical life of 10,000 times, this switch is built to withstand frequent use.
3. **Wide Temperature Range**: Operates efficiently in temperatures ranging from -25°C to +55°C, making it suitable for various environments.
4. **Certified Quality**: Comes with CQC and CE certifications, guaranteeing its safety and reliability.
Applications:
This switch is ideal for use in refrigerators, freezers, and other home appliances where a reliable door switch is required.
After-Sales Service:
We stand behind the quality of our products and offer excellent after-sales service. If you encounter any issues, our dedicated team is here to assist you.
Choose Yongxing KBM Series Refrigerator Door Switch for a reliable, durable, and cost-effective solution.
Why Choose Yongxing KBM Series Refrigerator Door Switch?
The Yongxing KBM Series Refrigerator Door Switch is a top choice for home appliances due to its durable PA66 material, high electrical life, and wide temperature range. It ensures reliable performance and longevity, making it ideal for refrigerators and freezers.
What Makes This Switch Stand Out?
This switch stands out with its CQC and CE certifications, guaranteeing safety and reliability. Its electronic structure and 1NO switch combination provide efficient operation, while the high insulation resistance ensures safety.
How Does It Benefit Your Business?
As a factory-direct supplier, we offer this switch at competitive wholesale prices, allowing you to save costs while ensuring quality. Its wide applicability in home appliances makes it a versatile choice for your inventory.
