Yongxing KCD Series 16A 250V 6-Pin Illuminated Rocker Switch | Factory Wholesale

500 - 1,999  pieces
$0.70

2,000 - 4,999  pieces
$0.65

>= 5,000  pieces
$0.60

0 reviews

Yongxing KCD Rocker Switch | Factory Wholesale | 16A 250V | Customizable

Description

Introducing the Yongxing KCD Series 16A 250V 6-Pin Illuminated Rocker Switch, a top-tier choice for cars, industrial machinery, and electric equipment. As a factory supplier, we offer wholesale pricing and customization options to meet your specific needs. Our switch boasts a maximum current rating of 16A and a voltage rating of 250VAC, ensuring reliable performance. With a mechanical life of 100,000 cycles and an IP41 rating, it’s built to last. The switch features a plastic housing and comes in black, with selectable button colors and lamp voltages (6V, 12V, 24V, 110V, 220V). It’s certified by CQC, CE, UL, CB, and ENEC, guaranteeing quality and safety. Our factory, equipped with independent plants, injection workshops, and advanced experimental equipment, ensures high standards in production. With over 60 senior engineers and 5S/5M management in all workshops, we deliver excellence. Choose Yongxing for reliable, customizable, and cost-effective solutions.
max.rating cnrrent 16A dielectrice resistance 1500V
max.rating voltage 250V electronic life 10000cycles
contact resistance 50mΩ operating temperature T55,T85,T125
insulation resistance 1000mΩ certifications CQC,CE,UL,CB,ENEC
housing color black(selective) button color black(selective)
PIN number 6 (selective2,3,4,6) lamp voltage 6V,12V,24V,110V,220V

Electronic component product image for cross-border e-commerceElectronic device product photo for e-commerce optimization


Why Choose Yongxing KCD Rocker Switch?

The Yongxing KCD Rocker Switch is designed for durability and versatility, making it ideal for cars, industrial machinery, and electric equipment. With a maximum current of 16A and a voltage of 250VAC, it ensures reliable operation under demanding conditions.

What Makes It Stand Out?

Our switch stands out with its high mechanical life of 100,000 cycles, IP41 rating, and customizable options. Choose from selectable colors and lamp voltages to meet your specific needs. Plus, it's certified by CQC, CE, UL, CB, and ENEC, ensuring quality and safety.

Why Buy from Us?

As a factory supplier, we offer wholesale pricing and customization services. Our factory is equipped with advanced equipment and managed by over 60 senior engineers, ensuring high standards in production. Choose Yongxing for reliable, cost-effective solutions.

Push Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch Customized

Additional information

Max. Current

16A

Max. Voltage

250VAC

Place of Origin

Shanghai, China

Brand Name

Yongxing

Model Number

KCD1

Application

Cars, Industrial, electric equipment

Material

plastic

Pins

6P

Whether the smart

NO

Mechanical Life

100000 Cycles

IP level

IP41

Switch Action

ON-OFF

Termination Type

Plug-in

pins

6

IP Rating

IP40
