Description
|
Product Name
|
ON Off Boat Rocker Switch Waterproof Button Toggle SPST Switch 2 Pin rocker switch
|
|
Certification
|
CQC,CE,UL,ENEC17
|
|
Whether the smart
|
NO
|
|
Place of Origin
|
Shanghai, China
|
|
Brand Name
|
yongxing
|
|
Model Number
|
KCD1-11-FA4A-B-B-01
|
|
Max. Current
|
16A
|
|
Max. Voltage
|
250v
|
|
Mechanical Life
|
100000 Cycles
|
|
Color
|
Black Boat Rocker Switch
|
|
Function
|
SPST
|
|
Certificate
|
CCC,CQC, CE, ENEC, UL
|
|
Operating temperature
|
T55,T85,T125
|
|
Electrical life
|
10000
|
|
Material
|
Plastic
|
|
Dielectric Strength
|
1500V AC 1min
|
|
Contact Resistance
|
≤50mΩ
|
Why Choose Our Waterproof Rocker Switch?
Our Yongxing KCD Series Waterproof Rocker Switch stands out for its robust plastic construction, ensuring longevity even in harsh environments. With an IP65 rating, it's highly waterproof and dustproof, making it ideal for outdoor and industrial applications.
What Are the Key Features?
This switch boasts a maximum current rating of 16A and a voltage of 250VAC, suitable for a wide range of uses. Its SPST function and ON-OFF switch action provide straightforward operation, while the plug-in termination type ensures easy installation. With a mechanical life of 100,000 cycles, it's built to last.
Why Buy from Us?
As a factory direct supplier and wholesaler, we offer competitive pricing without compromising on quality. We stand behind our product with excellent after-sales service, ensuring your satisfaction. Choose Yongxing for quality, reliability, and value.
