Description
| Contact Resistance | ≤50mΩ |
| Insulation Resistance | ≥1,000MΩ |
| Dielectric Resistance | 1,500V AC , 1 min |
| Electronic life(cycles) | 10,000 cycles |
| Mechanical life(cycles) | 50,000 – 100,000 cycles |
| Certification |
CQC , CE , UL , ENEC , CB |
| Max. Rating Current & Voltage (CQC , CE) |
16(4)A 250V AC T85 |
| Max. Rating Current & Voltage (UL) |
16R(4)A 250V AC , 16R(4)A 125V AC 1HP 125V AC |
| Max. Rating Current & Voltage (CB , ENEC) |
16(4)A 250V AC T125,10(4)A 250V AC T125 16(4)A 250V AC T85,16A 250V AC |
Why Choose Our Yongxing KCD1 Rocker Switch?
Our Yongxing KCD1 16A 250V 3-Pin Rocker Switch stands out for its durability, reliability, and versatility. Designed with a plastic body and available in multiple colors, it meets diverse application needs in cars, industrial equipment, and electric appliances. The switch is UL, CE, and ENEC certified, ensuring safe and efficient operation.
What Are the Key Features of Our Switch?
Our switch features a contact resistance of ≤50mΩ and insulation resistance of ≥1000MΩ, guaranteeing excellent electrical performance. With a mechanical life of 50,000-100,000 cycles and an electronic life of 10,000 cycles, it offers long-lasting durability. Additionally, it operates at temperatures ranging from T55 to T125 and has a dielectric strength of 1500V AC for 1 minute, making it suitable for various environments.
Why Buy from Us as a Wholesale Supplier?
As a factory-direct supplier, we offer competitive wholesale pricing on our Yongxing KCD1 Rocker Switch. We pride ourselves on providing quality products, reliable service, and fast delivery. Choose us for your electronic switch needs and experience the difference in quality and value.
