Yongxing KCD1 Waterproof Rocker Switch | Wholesale Supplier

500 - 1,999  pieces
$0.45

2,000 - 4,999  pieces
$0.42

>= 5,000  pieces
$0.39

0 reviews

Yongxing KCD1 Waterproof Rocker Switch | Wholesale Supplier | High Quality & Durable

Description

Introducing the Yongxing KCD1 Waterproof Rocker Switch, a high-quality, durable switch designed for a wide range of applications including cars, industrial machinery, and electric equipment. As a factory-direct supplier, we offer competitive wholesale prices and ensure top-notch quality. This switch features a 16A/250VAC rating, IP65 waterproof protection, and a robust mechanical life of 100,000 cycles, making it ideal for demanding environments. The SPDT ON-ON 3-pin configuration provides versatile connectivity options, while the black housing with white actuator adds a sleek, professional look. With a contact resistance of ≤50mΩ and insulation resistance of ≥1,000MΩ, this switch guarantees reliable performance. Our product is also CQC, CE, and ROHS certified, ensuring safety and compliance. Choose Yongxing for your switching needs and enjoy the benefits of factory-direct pricing and exceptional service.
item
value
Certification
CQC CE ROHS
KCD1-12-AA1A-B-WModel Number
KCD1-11-CA1A-B-B-01
Max. Current
16A
Max. Voltage
250VAC
Mechanical Life
100,000 cycles
Electronic Life
10,000 cycles
Dielectric Strength
1,500VAC,1min
Contact Resistance
≤50mΩ
Insulation Resistance
≥1,000MΩ
Operating Temperature
T85
Circuit
SPDT ON-ON 3Pin
Panel cutout
28×11 mm
Terminal
6.3×0.8 mm standard
Color
Black housing, white actuator
Marking
no marking
Material
PA66

Electronic component for cross-border e-commerceElectronic device part for online salesElectronic accessory for cross-border e-commerce


Why Choose Yongxing KCD1 Waterproof Rocker Switch?

The Yongxing KCD1 Waterproof Rocker Switch stands out for its exceptional durability and reliability. With an IP65 waterproof rating, it's perfect for use in harsh environments where moisture and dust are a concern. The 16A/250VAC rating ensures it can handle high currents and voltages, making it suitable for a wide range of applications.

What Are the Key Features?

Key features include a long mechanical life of 100,000 cycles, an electronic life of 10,000 cycles, and a compact 28x11mm panel cutout. The switch also offers a low contact resistance of ≤50mΩ and high insulation resistance of ≥1,000MΩ, ensuring optimal performance and safety.

Why Buy from Us?

As a factory-direct supplier, we offer competitive wholesale prices without compromising on quality. Our products are CQC, CE, and ROHS certified, giving you peace of mind regarding safety and compliance. Choose Yongxing for reliable, high-quality switches that meet your needs and exceed your expectations.

Push Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch Customized

Additional information

Max. Current

16A

Max. Voltage

250VAC

Place of Origin

Shanghai, China

Brand Name

Yongxing

Model Number

KCD1-12-AA1A-B-W

Application

Cars, Industrial, electric equipment

Material

Stainless Steel

Pins

3p

Whether the smart

NO

Mechanical Life

100,000 cycles

IP level

IP65

Switch Action

ON-OFF

Termination Type

Plug-in

Electronic Life

10,000 cycles

Dielectric Strength

1,500VAC,1min

Contact Resistance

≤50mΩ

Insulation Resistance

≥1,000MΩ

Operating Temperature

T85

Circuit

SPDT ON-ON

Panel cutout

28×11 mm

Terminal

6.3×0.8 mm standard

Color

Black housing, black actuator

Marking

NO marking
