Description
|
item
|
value
|
|
Place of Origin
|
Shanghai,China
|
|
Brand Name
|
SK(shangkai) yongxing
|
|
Model Number
|
KW11-12-A2AA-B
|
|
Max. Current
|
3A
|
|
Max. Voltage
|
250V
|
|
Operating Temperature
|
-25℃~+125℃
|
|
Protection Level
|
IP40 IP65
|
|
Contact Resistance
|
≤50mΩ
|
|
Insulation Resistance
|
≥100MΩ
|
|
Dielectric Strength
|
1500V
|
|
Electrical life
|
50,000
|
|
Operating Temperature Range
|
-25℃~+125℃
|
|
Lever type
|
Long Straight Lever
|
|
Lever Length
|
22.5mm
|
|
Certification
|
CQC ENEC
|
|
Protection Degree
|
IP40, IP65 is also available
|
|
Color
|
Black
|
Why Choose Our Yongxing KW11 Micro Switch?
Our Yongxing KW11 Micro Switch stands out with its long 22.5mm lever, providing precise and reliable operation. It's UL approved, ensuring safety and compliance with industry standards. With a wide operating temperature range and high electrical specifications, it's perfect for both industrial and household applications.
What Are the Key Features?
Key features include a 3A/5A rating, 250VAC, and a mechanical life of 50,000 cycles. It offers excellent insulation and dielectric strength, ensuring electrical safety. The switch is available in black with an IP40 protection level, and IP65 is also an option for enhanced durability.
Why Buy from Us?
As a direct supplier and factory, we offer competitive wholesale pricing, fast delivery, and exceptional customer service. Our micro switches are built to last, providing reliable performance in various applications. Choose us for quality, value, and peace of mind.
