Yongxing KW15 16A 250V Micro Switch – Wholesale Supplier Factory

100 - 999  pieces
$0.47

1,000 - 2,999  pieces
$0.46

>= 3,000  pieces
$0.43

0 reviews

Yongxing KW15 Micro Switch – Wholesale Supplier, Factory Direct, High Quality

Description

Introducing the Yongxing KW15 Series 16A 250V Micro Switch, a top-tier choice for domestic and industrial applications. As a factory direct supplier, we offer wholesale pricing on this high-quality micro switch. With a maximum current of 16A and voltage of 250V, it’s designed for reliability and durability. The switch features a plastic body, mechanical life of 100,000 times, and operates within a temperature range of -25°C to +125°C. Its IP40 protection level ensures safety in various environments. The KW15 Series is ideal for use in industrial machinery, electric power systems, and household appliances. With a short lever design, contact resistance ≤50mΩ, and insulation resistance ≥100mΩ, it outperforms many competitors. Dielectric strength of 1500V further guarantees its safety and reliability. Choose Yongxing for quality, affordability, and direct factory support.

Electronic component high-quality image for cross-border e-commerceElectronic device product image for cross-border e-commerceElectronic part detailed image for cross-border e-commerceElectronic product clear image for cross-border e-commerce


Why Choose Yongxing KW15 Micro Switch?

The Yongxing KW15 Micro Switch stands out for its high reliability and long mechanical life, making it ideal for industrial machinery, electric power systems, and household appliances. With a maximum current of 16A and voltage of 250V, it ensures stable performance under various conditions.

What Makes It Different?

Unlike many competitors, our micro switch features a plastic body with IP40 protection, ensuring safety and durability. Its short lever design, combined with low contact and high insulation resistance, guarantees efficient and safe operation. Dielectric strength of 1500V further enhances its reliability.

Why Buy From Us?

As a factory direct supplier, we offer wholesale pricing on the Yongxing KW15 Micro Switch. This means you get high-quality products at competitive prices, with the added assurance of direct factory support and after-sales service.

Push Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch Customized

Additional information

Whether the smart

NO

Max. Current

16A

Max. Voltage

250V

Place of Origin

Shanghai, China

Brand Name

Yongxing

Model Number

KW15-11B-AAA-BBB

Application

Industrial, electric power, households

Material

plastic

Mechanical Life

100000 times

Circuit

SPST

Operating Temperature

-25° ~ +125°

IP level

IP40

Lever

Short Lever

Contact Resistance

≤50mΩ

Insulation Resistance

≥100mΩ

Dielectric strength

1500V

Protection Level

IP40
