Yongxing LA133 22mm Rotary Switch – Wholesale Supplier

500 - 1,999  pieces
$4.30

2,000 - 4,999  pieces
$4.20

>= 5,000  pieces
$4.10

0 reviews

Yongxing LA133 22mm Rotary Switch – Wholesale Supplier

Description

Introducing the Yongxing LA133 Series 22mm Rotary Switch, a top-notch electrical component designed for durability and efficiency. As a factory-direct supplier, we offer wholesale pricing on this high-quality switch, which boasts a robust plastic construction and electronic structure, ensuring long-lasting performance. With a maximum current of 10A and a maximum voltage of 660 VAC, it’s suitable for a wide range of electric and industrial control applications. The switch features a round head design, screw and plug terminals, and is fully illuminated for easy visibility. It meets IP65 protection level standards, offering excellent resistance to dust and water ingress. With a mechanical life of 1,000,000 cycles and electrical lives of 600,000 cycles for AC-15 and 250,000 cycles for DC-13, it outperforms many competitors in terms of reliability and durability. Our factory-direct supply ensures competitive pricing and reliable availability, making it an ideal choice for bulk purchases.
item
value
Place of Origin
Shanghai,China
Brand Name
Sk(shangkai) yongxing
Model Number
LA133-B1.Y2S-K20
Protection Level
IP40 IP65 IP67
Max. Current
10A
Max. Voltage
660 VAC
Rated Insulation Voltage
660v ac
Rated Thermal Current
10A
Max.insulation voltage
2500 V/min
Usage Category
AC-15 DC-13
Mechanical Life
1000,000
Operation frequency
1200 cycles/h
Electrical life for AC-15
600000 cycles
Electrical life for DC-13
250000 cycles
Mounting Hole Size
22mm Diameter

Why Choose Yongxing LA133 Rotary Switch?

The Yongxing LA133 Rotary Switch stands out with its durable plastic construction and electronic structure, ensuring reliable performance in electric and industrial control applications. Its fully illuminated design and high IP65 protection level make it ideal for demanding environments.

What Are the Key Features?

Key features include a 10A max current, 660 VAC max voltage, screw and plug terminals, and a long mechanical life of 1,000,000 cycles. It also offers excellent electrical lives for AC-15 and DC-13, making it a versatile choice for various applications.

Why Buy from Us?

As a factory-direct supplier, we offer wholesale pricing and reliable availability. Our commitment to quality ensures that you receive a product that meets or exceeds industry standards, making the Yongxing LA133 Rotary Switch a smart investment for your business.

Push Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch Customized

Additional information

Max. Current

10A

Max. Voltage

660 VAC

Place of Origin

Shanghai, China

Brand Name

Yongxing

Model Number

LA133-B1

LED

Yes

Application

Electric, Industrial Control

Material

plastic

Structure

Electronic

Head Type

Round Head

Terminal Type

Screw Terminal, Plug Terminal

Whether the smart

NO

illuminated Type

full illuminated

IP level

IP65

Switch Combination

1NO1NC

Rated Insulation Voltage

660v ac

Rated Thermal Current

10A

Max.insulation voltage

2500 V/min

Usage Category

AC-15 DC-13

Mechanical Life

1000,000

Operation frequency

1200 cycles/h

Electrical life for AC-15

600000 cycles

Electrical life for DC-13

250000 cycles

Mounting Hole Size

22mm Diameter

Protection Level

IP40 IP65
