Yongxing MA Series 3A 250V Waterproof Rotary Metal Switch | Factory Wholesale

500 - 1,999  pieces
$3.83

2,000 - 4,999  pieces
$3.81

>= 5,000  pieces
$3.79

0 reviews

Factory Wholesale Yongxing MA Series Rotary Metal Switch, 3A 250V, Waterproof, Durable.

Description

Our Yongxing MA Series Rotary Metal Switch is a high-quality, durable, and waterproof solution designed for various applications. With a maximum current of 3A and a maximum voltage of 250V, this switch is suitable for instruments, industrial control systems, and electric equipment. Made from premium metal, it features pin terminals, a 180° rotation range, and a mechanical life of 50,000 times. The IP65 rating ensures excellent waterproof performance, making it ideal for harsh environments. Our switch also boasts low contact resistance (≤50mΩ), high insulation resistance (≥100MΩ), and can withstand 1500VAC at 50Hz for 1 minute. The electrical life is 25,000 times, and it operates within a temperature range of -25℃ to 55℃. Available in silver, with red, yellow, green, blue, or white color options for the light, and flat, high, or ball head types, this switch offers customization to meet your specific needs. Certified by CQC and CE, it guarantees quality and safety. As a factory supplier, we offer wholesale prices and excellent after-sales service, ensuring you get the best value for your money.

Electronic component product image for cross-border e-commerce


Why Choose Our Yongxing MA Series Rotary Metal Switch?

Our Yongxing MA Series Rotary Metal Switch stands out for its durability, waterproof performance, and wide range of applications. With a maximum current of 3A and a maximum voltage of 250V, it is suitable for various industrial and commercial uses. The metal construction ensures longevity, while the IP65 rating guarantees protection against water and dust, making it ideal for harsh environments.

What Are the Key Features of This Switch?

Key features include a 180° rotation range, pin terminals for easy installation, and a mechanical life of 50,000 times. It also has low contact resistance (≤50mΩ) and high insulation resistance (≥100MΩ), ensuring reliable performance. The switch can withstand 1500VAC at 50Hz for 1 minute, and its electrical life is 25,000 times. Additionally, it is available in multiple colors and head types, allowing for customization.

Why Buy from Us as a Factory Supplier?

As a factory supplier, we offer wholesale prices, ensuring you get the best value for your money. Our switches are certified by CQC and CE, guaranteeing quality and safety. We also provide excellent after-sales service, so you can buy with confidence. Choose our Yongxing MA Series Rotary Metal Switch for a reliable, durable, and cost-effective solution.

Push Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch Customized

Additional information

Whether the smart

NO

Max. Current

3A

Max. Voltage

250V

Place of Origin

Shanghai, China

Brand Name

Yongxing

Model Number

MA16

Application

Instrument, Industrial Control, electric equipment

Material

Metal

Terminal Type

Pin terminal

Rotation Range

180°

Mechanical Life

50000 times

IP level

IP65

Contact Resistance

≤50mΩ

Insulation Resistance

≥100MQ

Withstand voltage

1500VAC 50Hz 1min

Electrical life

25000 Times

Mechanical life

50000 Times

Working ambient temperature

-25℃~55℃

Shell material

stainless steel, brass

Color with light

red/yellow/green/blue/white

Head type

flat/high/ball head

Certification

CQC, CE
