Description
Introducing the Yongxing MA19 19mm Waterproof Metal Switch, a high-quality product designed for durability and performance. As a factory direct supplier, we offer competitive wholesale prices. This switch boasts a stainless steel and brass construction, ensuring robustness and longevity. With an IP65 rating, it provides excellent waterproof protection, making it ideal for outdoor and industrial applications. The switch supports a maximum current of 3A and a maximum voltage of 250V, with a rated voltage of 250V, ensuring reliable operation in various electrical environments. It features a round head design with pin terminals, a 1NO1NC switch combination, and a contact resistance of ≤50mΩ, offering precise control and low energy loss. The insulation resistance is ≥100MΩ, and it can withstand voltages up to 1500VAC for 1 minute at 50Hz, ensuring safety and reliability. With an electrical life of 25,000 times and a mechanical life of 50,000 times, this switch is built to last. It operates efficiently in temperatures ranging from -25℃ to 55℃, making it suitable for a wide range of environments. Available in silver with red, yellow, green, blue, or white light options, and flat, high, or ball head designs, it meets diverse aesthetic and functional needs. Certified by CQC and CE, it guarantees quality and compliance with international standards. Choose Yongxing for reliable, factory-direct switches at wholesale prices.
Why Choose Yongxing MA19 Waterproof Metal Switch?
The Yongxing MA19 Waterproof Metal Switch stands out with its durable stainless steel and brass construction, ensuring long-lasting performance. Its IP65 rating provides excellent waterproof protection, making it ideal for outdoor and harsh industrial environments. With a maximum current of 3A and a maximum voltage of 250V, it offers reliable operation in various electrical setups.
What Are the Key Features?
This switch features a 1NO1NC combination, precise contact resistance of ≤50mΩ, and high insulation resistance of ≥100MΩ, ensuring safety and efficiency. It can withstand voltages up to 1500VAC for 1 minute at 50Hz, and has an impressive electrical life of 25,000 times and a mechanical life of 50,000 times. The switch operates efficiently in temperatures ranging from -25℃ to 55℃, making it versatile for different climates.
Why Buy from Us?
As a factory direct supplier, we offer competitive wholesale prices on the Yongxing MA19 Waterproof Metal Switch. Our products are certified by CQC and CE, guaranteeing quality and compliance with international standards. Choose Yongxing for reliable, high-quality switches that meet your electrical needs.
