Description
Product Specifications:
- Max. Current: 5A
- Max. Voltage: 250VAC
- Operating Temperature: -25℃~+125℃
- Dielectric Strength: 1500V
- Electrical Life: 50,000 Cycles
- Mechanical Life: 50,000 times
- Circuit: SPDT, SPST, DPST, DPDT
- Material: High-quality plastic
- Contact Resistance: ≤50mΩ
- Insulation Resistance: ≥100mΩ
- Protection Level: IP40
- Certification: ULCUL
Product Advantages:
- Low Operating Force: Our micro switch requires minimal force to operate, ensuring smooth and precise control.
- Wide Temperature Range: With an operating temperature range of -25℃ to +125℃, it’s suitable for various environments.
- Long Electrical Life: Rated for 50,000 cycles, this switch offers durability and reliability.
- Customization Available: For large quantities, we can customize the switch to meet your specific requirements.
- Factory Direct: As a factory supplier, we offer competitive prices and direct access to our products.
After-Sales Service: We provide comprehensive after-sales service, including technical support and warranty coverage, ensuring your satisfaction with our product.
Why Choose Us?
We are a reputable factory supplier with independent plants, injection workshops, and advanced experimental equipment. Our team of over 60 senior engineers ensures the highest quality standards. All workshops adhere to 5S and 5M management standards, guaranteeing consistent product quality. Contact us today to discuss your wholesale needs and experience the Yongxing difference!
|
dielectric strength
|
1500v
|
||
|
electronic life
|
50000
|
||
|
operating temperature
|
-25℃~125℃
|
||
|
max.rating current & voltage
|
5(1)A 250vac T105u 5E4
3A 250VAC T105 u 5E4
16a(10a)(4a)(3a)(15a) 250/125vac
|
Why Choose Yongxing Electrical Micro Switch?
Our Yongxing Electrical Micro Switch stands out for its low operating force, making it perfect for applications requiring precise control. With a wide operating temperature range and long electrical life, it ensures reliability and durability in various environments.
What Are the Key Features?
Key features include a max. current of 5A, max. voltage of 250VAC, and a dielectric strength of 1500V. It also offers multiple circuit options (SPDT, SPST, DPST, DPDT) and is made from high-quality plastic, ensuring excellent performance.
Can We Customize the Switch?
Yes, for large quantities, we can customize the switch to meet your specific requirements. As a factory supplier, we have the flexibility and capability to tailor our products to your needs.
