Description
|
item
|
value
|
|
Certification
|
CQC CE ROHS
|
|
KCD1-12-AA1A-B-WModel Number
|
KCD1-11-CA1A-B-B-01
|
|
Max. Current
|
16A
|
|
Max. Voltage
|
250VAC
|
|
Mechanical Life
|
100,000 cycles
|
|
Electronic Life
|
10,000 cycles
|
|
Dielectric Strength
|
1,500VAC,1min
|
|
Contact Resistance
|
≤50mΩ
|
|
Insulation Resistance
|
≥1,000MΩ
|
|
Operating Temperature
|
T85
|
|
Circuit
|
SPDT ON-ON 3Pin
|
|
Panel cutout
|
28×11 mm
|
|
Terminal
|
6.3×0.8 mm standard
|
|
Color
|
Black housing, white actuator
|
|
Marking
|
no marking
|
|
Material
|
PA66
|
Why Choose Our Waterproof Rocker Switch?
Our waterproof rocker switch is designed to withstand harsh environments, making it ideal for outdoor and industrial applications. With IP65 waterproof protection, it ensures reliable performance even in wet conditions. The switch's high current and voltage ratings make it suitable for heavy-duty tasks, while its long mechanical and electronic life guarantee durability. As a factory supplier, we offer competitive prices and bulk discounts, making it a cost-effective choice for wholesale buyers.
What Are the Key Features of Our Switch?
Our switch features a rubber cover for enhanced waterproofing, a black housing with a white actuator for a sleek look, and a standard 6.3x0.8mm terminal for easy connection. It has a T85 operating temperature range, making it suitable for a wide range of environments. The switch's SPDT ON-ON circuit configuration provides versatile switching options, meeting various application needs.
How Does Our Switch Compare to Others?
Compared to other switches on the market, our waterproof rocker switch stands out for its high-quality materials, reliable performance, and competitive pricing. As a factory supplier, we have full control over the manufacturing process, ensuring consistent quality and timely delivery. Our switch's long mechanical and electronic life also means fewer replacements and lower maintenance costs for you.
